Steering Pump RUSSIA 153461.123
RUSSIA 153461.123
- OEM REF.：
- 153461.123
- CNA NO.：
- CNA-G114-3411010 LH
请选择规格
- Quantity：
Stock：0 pcs Sold：0 pcs
-
Steering Pump RUSSIA 153461.1230 US$
Total：0 US$
Applicable Front A×le Load 1500kg
Power Cylinder Diameter 75mm
Rated Work Pressure 10MPa
Recommend Pump Flow Rate 8 L/min
Circles 4.0r
Output Angle ±41.7°
Oil Inlet Hole M14×1.5
Oil Outlet Hole M16×1.5
Input Shaft Spline Φ20
Output Shaft Spline Φ29.66×36
| information | |
|---|---|
| CNA NO. | CNA-G114-3411010 LH |
| OEM REF. | 153461.123 |
| Applicable Front A×le Load | 1500kg |
| Power Cylinder Diameter | 75mm |
| Rated Work Pressure | 10MPa |
| Recommend Pump Flow Rate | 8 L/min |
| Circles | 4.0r |
| Output Angle | ±41.7° |
| Oil Inlet Hole | M14×1.5 |
| Oil Outlet Hole | M16×1.5 |
| Input Shaft Spline | Φ20 |
| Output Shaft Spline | Φ29.66×36 |
| Suitable for | RUSSIA |
