Steering Gear Box NISSAN FE6T Oil holes with connector
NISSAN FE6T Oil holes with connector
- OEM REF.：
- FE6T Oil holes with connector
- CNA NO.：
- CNA-D103-1-3411010 RH
请选择规格
- Quantity：
Stock：0 pcs Sold：0 pcs
-
Steering Gear Box NISSAN FE6T Oil holes with connector0 US$
Total：0 US$
Applicable Front A×le Load 4500kg
Power Cylinder Diameter 90mm
Rated Work Pressure 13MPa
Recommend Pump Flow Rate 14L/min
Circles 5.38r
Output Angle ±45°
Oil Inlet Hole M18×1.5
Oil Outlet Hole M18×1.5
Input Shaft Spline Φ21.775×36
Output Shaft Spline Φ42.12x36
| information | |
|---|---|
| CNA NO. | CNA-D103-1-3411010 RH |
| OEM REF. | FE6T Oil holes with connector |
| Applicable Front A×le Load | 4500kg |
| Power Cylinder Diameter | 90mm |
| Rated Work Pressure | 13MPa |
| Recommend Pump Flow Rate | 14L/min |
| Circles | 5.38r |
| Output Angle | ±45° |
| Oil Inlet Hole | M18×1.5 |
| Oil Outlet Hole | M18×1.5 |
| Input Shaft Spline | Φ21.775×36 |
| Output Shaft Spline | Φ42.12x36 |
| Suitable for | NISSAN |
