Steering Gear Box NISSAN 48083-Z1012
NISSAN 48083-Z1012
- OEM REF.：
- 48083-Z1012
- NISSAN 4 holes
- CNA NO.：
- CNA-C106-1-3411010 RH
请选择规格
- Quantity：
Stock：0 pcs Sold：0 pcs
-
Steering Gear Box NISSAN 48083-Z10120 US$
Total：0 US$
Applicable Front A×le Load 75KN
Power Cylinder Diameter 100mm
Rated Work Pressure 13MPa
Recommend Pump Flow Rate 16-22L/min
Circles 6.4r
Output Angle ±47.5°
Oil Inlet Hole M18×1.5
Oil Outlet Hole M18×1.5
Input Shaft Spline M0.5×39
Output Shaft Spline Φ55.5×36
| information | |
|---|---|
| CNA NO. | CNA-C106-1-3411010 RH |
| OEM REF. | 48083-Z1012/NISSAN 4 holes |
| Applicable Front A×le Load | 75KN |
| Power Cylinder Diameter | 100mm |
| Rated Work Pressure | 13MPa |
| Recommend Pump Flow Rate | 16-22L/min |
| Circles | 6.4r |
| Output Angle | ±47.5° |
| Oil Inlet Hole | M18×1.5 |
| Oil Outlet Hole | M18×1.5 |
| Input Shaft Spline | M0.5×39 |
| Output Shaft Spline | Φ55.5×36 |
| Suitable for | NISSAN |
